I just the Fontlab autohinter and then use the autofill button to have it gather the standard stem values. Then just delete the Fontlab hints.

I just the Fontlab autohinter and then use the autofill button to have it gather the standard stem values. Then just delete the Fontlab hints.

Up till now I also have used FontLab for computing the standard stems, but that solution is semioptimal. Just open an Adobe original font in FontLab and remove (and forget) the original standard stems. Then try to reproduce the same quality. I would like to know, what exactly I have to measure and why the optimal standard stems are dependent from the number of pixels, in which the font is displayed. The setsnap.pl script indicates, that there are no optimal stems independent from the absolute resolution. But for example, for which size does Adobe optimize the stems and how do they fine tune them? Additionally it does not seem to be needed, that the standard stems match with any real stem width, for example: You have three real horizontal stem widths 10, 18 and 32 units, but your tests show, that you should take one only. So you could sum the three values and devide them by three. The result is 20. Your whole font does not contain a stem with a width of 20, but the rasterizer can make use of the value 20. (This naturally does not mean, that just 20 is the optimal value.) I assume, that FontLab computes standard stems only, that match with real stems. And if not, I would like to know, how FontLab computes the values. By the way the computed values are dependent from the hints, that exist in the font. Change the hints and FontLab computes different standard stems. All this is too arbitrary for being professional. The fact, that there are still so many non Adobe fonts, that are not well hinted, indicates, that there is a need for clarifying the problem. PostScript hinting is not magic. I keep my hands from TrueType hinting, but I really want to understand, how exactly PostScript hinting works. David Lemon’s tutorial is cool and his writing style eases the understanding, but it is not enough. I need more info. The individual hints are not the problems, but the standard stems are a big one in my opinion. (I also have a need for clarifying the exact influence of the BlueShift and the BlueScale value. I got info about the meaning from the Type1 blackbook, but the info is too compressed and partly too cryptical.)

Arno,

The setsnap.pl Perl script was originally a C program that I wrote in the early 1990s. I ported it to Perl three or four years ago.

Like you, I do not run this script directly, but instead have a batch file, which happens to be another Perl script, that invokes it with specific options.

The default behavior of setsnap.pl is to simply indicate the highest-frequency stem widths. It is expected to use the output of another AFDKO tool, specifically stemHist, as its input. The stemHist tool outputs two files, one for horizontal stems, and another for vertical ones.

I have found that selecting appropriate stem values is a combination of art, science, and philosophy. The easiest and fastest approach is to simply take the highest-frequency stem values, for horizontal and vertical. For many purposes, this will provide adequate results. Our rendering experts have always claimed that having no hints is better than having poor hints. Selecting the highest-frequency stems could never be construed as having poor hints.

One point of more careful selection of stem values involves a range within which the stems result in the same relative rendered size. The parameters are resolution and point size. If you set these (the setsnap.pl tool has options for these, but also has defaults if they are not set, specifically 72-dpi for the resolution, and 9- through 24-point as the point size range), you can experiment with various values.

In the past, like nearly twenty years ago, we set the hinting parameters for our Japanese fonts by looking at only one or two rowfonts for each hint dictionary. For the kanji, this meant using only a small fraction of the glyphs to determine these values. When I originally wrote setsnap.pl in C, which was simply called setsnap, one purpose was to be able to use all of the rowfonts to calculate the stem values. (The purpose of setsnap.pl's "-s" option, which was also a feature of the original C version, is to additionally output a new stemHist file, and it assumes that its input is a bunch of them that have been concatenated from multiple rowfonts.) This resulted in much more accurate stem values, even if the highest-frequency one is to be selected.

If you select only one stem value for horizontal and vertical, these become the StdHW and StdVW values of the font dictionary, respectively. You can also set the StemSnapH and StemSnapV arrays, meaning that multiple values are specified. Whether multiple values need to be specified depends on the font data. My "rule of thumb" is to keep multiple StemSnapH and StemSnapV values at least 10 units apart. And, as you are no doubt aware, one of the StemSnapH and StemSnapV values must be the same as set for the StdHW and StdVW values, respectively. If the output of the setsnap.pl tool suggests that there are two or three high-frequency stems that are at least 10 units apart, it would be a good idea to specify these in the StemSnapH and StemSnapV arrays, being sure to include the highest-frequency one as the StdHW and StdVW values. (The setsnap.pl tool outputs the highest-frequency stem, so you need to look into the output of stemHist to find others.)

As an example, here is the horizontal stemHist output for the "Kanji" hint dictionary of RyoDispPlusN-Heavy (created by using the setsnap.pl "-s" option to concatenate multiple stemHist output files):

Count Width
536 7
254 8
262 9
266 10
879 11
1623 12
1033 13
279 14
167 15
35275 16
576 17
559 18
264 19
207 20
212 21
218 22
229 23
414 24
346 25
383 26
522 27
626 28
429 29
615 30
858 31
774 32
393 33
1031 34
201 35
121 36
43 37
20 38
47 39
22 40
72 41
18 42
12 43
24 44
17 45
15 46
26 47
8 48
11 49
223 50
9 51
6 52
12 53
20 54
10 55
2 56
16 57
14 58
8 59
67 60
15 61
15 62
4 63
4 64
2 65
10 66
6 67
7 68
4 69
9 70
12 71
8 72
8 73
10 74
15 75
8 76
17 77
14 78
15 79
13 80
14 81
18 82
10 83
13 84
21 85
12 86
20 87
20 88
24 89
22 90
19 91
29 92
41 93
55 94
22 95
25 96
33 97
22 98
35 99
29 100
32 101
27 102
35 103
43 104
50 105
40 106
67 107
68 108
51 109
43 110
61 111
64 112
45 113
46 114
40 115
63 116
69 117
59 118
40 119
60 120
52 121
42 122
84 123
60 124
67 125
52 126
45 127
77 128
158 129
48 130
99 131
53 132
24 133
60 134
29 135
40 136
37 137
37 138
15 139
43 140
35 141
36 142
51 143
57 144
43 145
42 146
18 147
36 148
35 149
26 150
17 151
32 152
35 153
31 154
27 155
13 156
34 157
19 158
28 159
24 160
14 161
19 162
12 163
53 164
11 165
44 166
22 167
10 168
41 169
12 170
6 171
6 172
66 173
7 174
10 175
7 176
4 177
8 178
3 179
2 180
47 181
4 182
6 183
2 184
1 185
3 187
2 188
2 189
3 190
1 191
4 192
1 193
3 195
2 196
1 199
1 200
1 201
1 202
1 206
1 213
1 222

It is little wonder that setsnap.pl indicates that "16" is the highest-frequency horizontal stem value, with 35,275 hits. (Keep in mind that the "Kanji" hint dictionary of this font includes glyphs for approximately 8,000 kanji.) In fact, the stem value of 16 is such a high frequency that we set only StdHW for this font, specifically a value of 16, and do not include a StemSnapH array. If I were to set a StemSnapH array, the stem value of 34 would be a likely candidate to include in it.

Hopefully this helps to some degree...

Dr. Ken Lunde
Senior Computer Scientist, CJKV Type Development
Adobe Systems Incorporated
lunde@adobe.com

Thanks, Ken! I try again to comprehend and reproduce the standard stems of some Adobe fonts.

You are overthinking this :)

Arno,

Your goal should not be to reproduce the standard stems of some of our fonts, because there are no "correct" values. Rather, think of this exercise in terms of choosing one of many possible "correct" or "appropriate" values.

Science is used to reveal candidate stem values, either through simplistic calculations (highest-frequency, for example), or more complex ones (as the "-o" option of setsnap.pl uses, which takes resolution and point size ranges into account).

Philosophy is then used to pick from among the candidate values, and a good rule is that if you cannot decide between two relatively close values, choose the lower of the two.

Art even comes into play. Experience is also another factor.

I also agree that you should not overthink this.

If you'd like me to take a stab at a font, feel free to send to me the stemHist output files, and I'll let you know what I think are appropriate stem values.

Dr. Ken Lunde
Senior Computer Scientist, CJKV Type Development
Adobe Systems Incorporated
lunde@adobe.com

Bold or black fonts, in which the contrast is stronger, seem to need more values.

I don't think it's the contrast. There are often more quite distinct (numerically far apart) stem widths in the heavier weights.
That's because with reference to the desirability of an overall even quality in text, "colour" (or notan) is more apparent and more instrumental in bold weights than the thickness of stems.
For instance, Futura:

H
H
H
H

ChrisL

If you’d like me to take a stab at a font, feel free to send to me the stemHist output files, and I’ll let you know what I think are appropriate stem values.

Thanks, Ken. I would also send you a list of standard stems, from which I think, that they are well chosen.

But another question: Imagine, that you have a font with the following real stem widths. (The font does not have any curves.)

VERTICAL STEMS: 30 and 60
HORIZONTAL STEMS: 40 and 50

Then I would set the following vertical standard stems:
30 and 60

But I would think about deviding the sum of 40 and 50 for the one and only value of the horizontal standard stems, because the rasterizer tries to render in the width of the standard stems independent from the question, if their widths match with real stems. Would this be wrong? More to the point, there is no duty to choose standard stems, that really exist in the font, isn’t it? If, for example, the regular style and the italic style of a font are very similar in weight, I could use the same standard stems for both styles.

And another thing with regard to bold and black styles: In my opinion it sometimes is better, not to provide any hints for those bold and black styles, but standard stems only. This often looks more smooth. Or alternatively vertical and horizontal standard stems, but vertical hints only. (Vertical hints hint horizontal stems.) Or as very elegant alternate way, vertical and horizontal standard stems and vertical ghost hints, that are exactly on the top and under the bottom of each glyph. I don’t know, whether that works, but I had this idea, when I saw the bar of a small t, which should align with the other small letters. I could not extend the alignment zone down to the top of the bar of the t, because there seems to be a maximum allowed width of alignment zones, but I have successfully aligned the bar of the t with the help of a ghost hint. (When I tried to extend the alignment zone down to the bar of the t, the alignment of all the other small letters did not work anymore.) And, surprise, if the ghost hint overlaps with the bar of the t and with the alignment zone, it will be additionally hinted.

Yes, it may be, that I overthink this, but it really is hard to get detailed information about hinting without asking experts. The only tutorial with regard to PostScript-hinting seems to be David’s.

----------

Ken, I already have posted a bug report on the FontLab forum about the autohinting macro of the latest AFDKO. (The option "suppress hint substitution" does not work for sure and the option "allow changes in outlines" doesn’t seem to work.) But maybe it is better to contact the developers directly. Is there a better place, on which I can report bugs?

My bug report of the autohinting macro, that is contained in the AFDKO.
I have fixed the bug and attached it there.

I can edit my first message only. Why not the last one? That’s odd.

Quoting myself
(Vertical hints hint horizontal stems.)

This is a point, in which I am not sure. In Fontographer hints of horizontal stems are displayed as vertical arrows. In FontLab they are displayed as two dashed horizontal lines. And in the FontLab terminology a vertical hint hints a vertical stem. On the one side the FontLab terminology is more intuitive. On the other side it is contradictory regarding to the alignment function of hints. And it ignores the difference between a normal and a ghost hint. So I prefered to call a hint, that hints a vertical stem, a horizontal hint. But I am relatively sure, that it is defined in a specification. I only have to find it.

Edited:

From the Type1 blackbook:

The vstem hint, for each vertical stem (such as the legs of the
letter “n” or the leftmost and rightmost sections of the letter “o”)
takes two x values (expressed as x and delta-x) as arguments. These
two x values indicate the horizontal range that the vertical stem’s
width occupies in character space.

I change my opinion and call vstem hints vertical hints in future. Or vstem hints.

Sorry the hinting documentation is so limited. The tutorial I wrote so long ago was focused on Fontographer, and omitted things that FOG can't do. We are (more accurately: Miguel is) working on an expanded version, but it's a slow project and likely to take quite a while longer.

Arno asked:
But I would think about dividing the sum of 40 and 50 for the one and only value of the horizontal standard stems, because the rasterizer tries to render in the width of the standard stems independent from the question, if their widths match with real stems. Would this be wrong? More to the point, there is no duty to choose standard stems, that really exist in the font, isn’t it?

There's no requirement that the standard stem weights match actual stems. Often the best result is more of an average of several closely-related values. But it does need to really represent the weight of the design.

If, for example, the regular style and the italic style of a font are very similar in weight, I could use the same standard stems for both styles.

This would be a bad idea. The rasterizer tries to make a visible difference between the regular and bold weights at small sizes (where both may have one-pixel stems), and uses the stem weight values to figure out what weights it's dealing with. If you lie to the rasterizer you're not likely to get good results.

@ David or Miguel

Is the expanded version already available? I even would be interested in it, if it is in a beta stadium.
