This is one reason why small caps should be designed slightly larger than the x-height (height of the lowercase 's'). What typeface are you using?

That always bugged me when I was art directing.
My solution was to use the
< sc > TV < /sc > s
style, but bump up the size of the small caps a tad, so that there was a noticeable difference from lower-case x-height.

Occasionally, if the face had a larger small cap, that wasn't necessary, so that's the way I make my small caps now.

I wouldn't use small caps for something like "TV". Usual practice is to use full caps for two or three letters, and small caps for four letters or longer. I can't think of any of the latter that would ever be pluralized, with the exception of OB/GYNs which I think has been making the move to lowercase lately.

I can’t think of any of the latter that would ever be pluralized,

Financial products, e.g. RRSPs, RRIFs, RESPs. These are Canadian, but I would imagine there are similar things in other countries.

A related thread about small caps in mixed-case abbrevations like PhD, GmbH &c.

I wouldn't use small caps either, no matter how many letters -- and that's a position supported by pretty much every North American style guide. Chicago says, however,

The alternative use of small capitals for acronyms is followed by some publishers, but the University of Chicago Press favors the use of full capitals.

Like most editorial decisions, it's a matter of sticking with a choice: that one can justify a choice certainly helps. :-)

I've read that American magazines will often go sc for acronyms at 4 or more letters. To me it would look strange to see 3 and 4 letter acronyms mixed in a list, or even in the same text.

Here's one to add to the sc pile of queries—what do you do with a possessive apostrophe in a heading set in sc? My instinct would be to drop it down so it optically fit as if the heading was in all caps.

Mine would be to rewrite it. ;-)

Acronyms of more than 3 characters can get really horsey looking and stand out too much, which is why I think a lot of mags favor reducing them. But I don't think The New Yorker uses true small caps, I believe they just make the acronyms a point size or two smaller than the text.

Mine would be to rewrite it. ;-)

Always the best solution.

Your question illustrates an important issue, though: typography isn't necessarily the first (and in some cases, only) solution folks need to look at when faced with having to "fix" a problem. :-)

Stephen — We are using Bembo Book MT Pro. The small caps do sit just above the x-height but not very. Bumping them up .25–.5 pt might work.

Nick — We are a Canadian magazine with the majority of our readers being in the states. We also distribute to the UK & EU, Australia, and South America. So it is difficult to match our art direction with regional tastes and typographic etiquette.

Linda & Jupiterboy — The article this problem is concerned with is about military technology. Their language seems to be riddled with acronyms and abbreviations. Re-writing is mostly out of the question.

Thanks for all the help.

Ah, the clarification is useful.

I've worked on stuff like that -- I'm assuming you have a U.S.-oriented style/spelling guide -- and bumping up the small caps as you mention is likely the best solution to your specific problem. (The rewriting suggestion was for the specific problem of inserting a possessive apostrophe: it's definitely not a "one-size-fits-all" one.)

Re-writing is mostly out of the question.

Affirmative. ;-)

Maybe off-topic, but don't you think if they design the small caps to work with the lowercase they would be moving to far away from them working with the uppercase? (Which is, of course, the real use.)

There are many ways that small caps can work.
A typeface would need at least THREE kinds (i.e. three different heights) to satisy them all.

1. This is probably the most useful, noticeably taller than lower-case x-height. Good for acronyms, and still plenty of size contrast with full caps (unless the full capitals are smallish). Also a good size for Cyrillic small caps, where Maxim Zhukov has argued that size differentiation from lower case is helpful, given the commonality of so many letter forms between the Cyrillic upper and lower case, and the few extenders, especially in Russian.

2. These could be termed moyen caps and petite caps. The petite caps are the same height as lower-case x-height. Moyen caps would be larger than small caps, to allow sufficient contrast with petite caps for setting this kind of titular alphabet soup.

3. A traditional way of setting petite caps, with copious lettespacing.

A fourth size of small caps (bébé?) might be necessary to deal with "Mc/Mac" names that are set in all small caps, although this is so infrequent that the typographer should best handle it by tweaking, rather than with a separate font. If foundries wish to remedy the situation in-font, perhaps just two glyphs, "Scots A and C for small caps", would do the job.

Another issue is ordinals and superiors--occasionally, typographers may wish to set these in capital letter style.

So, my thinking is that the ultimate solution would be to include small caps in the main font, and have a separate Caps font, which contains moyen and petite cap sizes at the basic upper and lower case keystrokes, and also has superiors that are capital in form.

With this configuration, the difficult titles (B.Des etc.) could be set entirely with the Caps font, simplifying that chore for the typographer. Small caps could also be included, so that it would be possible to set both moyen caps with petite caps (basic "upper and lower" keystrokes) and moyen caps with small caps (small caps feature applied), as separate styles.

Ooo.... Nick, you're gonna make Miguel squeal when he hears of this. See the thread OpenType small caps in a separate font? by Adam Twardoch.

Doesn't Mrs. Eaves have regular and petite caps? Love'em! Keep'em comin'!

I'm having déjà vu suddenly. I think there is a thread about this where you, Nick, say those exact same things.

I like petite small caps, but they are too small to use in text settings. I'd consider them more a nicety than a necessity. I also think is someone were to use moyen and regular small caps in the same setting don't you think the page would start to become spotty?

FF Atma offers 4 (four) sizes of caps with corresponding figures and punctuation.

déjà vu

I wouldn't be surprised if I'm repeating myself without realizing it! (Doesn't everyone?)

I'm not familiar with Atma. It's nicely done, but not the kind of conservative design I would have looked at twice in 2001, or subsequently recognize in use, and I probably didn't notice the multi-small-caps, as that's something that has only really interested me since I started working in OpenType. Thanks for bringing it to my attention Stephen.

I see that Atma is pre-OpenType, and has Small Caps = Petite Caps, Mid Caps = Small Caps, and Quarter Caps = "Moyen" Caps.
Presumably its terminology was adopted prior to an awareness of how things shaped up in the OpenType Feature Tag specifications.
I wonder how Atma's various small caps will be implemented in OpenType...

Me too! It shouldn't be long now.
